PCL D10 Wall Mount Automatic Tire Inflator

Description

PCL D10 wall-mounted unit designed with gas stations in mind. The D10 offers repeatable accuracy and reduced maintenance costs.

Features:

• Consistent, cost-effective provision of high levels of safe air inflation services
• Strong marketing potential with modern design, bespoke graphics, and user-friendly air provision
• Plug and play – tire inflator with three pre-selectable application modes
• Low lifetime costs – long product life with robust design and proven electronics
• Low and simple maintenance with excellent diagnostics
• Customization to meet individual needs and applications
• Guaranteed accuracy with individual testing
• Electronic pressure preset
• Auto start inflation
• Clear display for easy customer usage
• Default to safe-setting
• Robust, high reliability and modern design with die-cast aluminum housing
• Ceramic sensor – accuracy to +/-0.5% of the full-scale reading
• An attractive and durable membrane with customizable graphics
• Can inflate accurately with hoses up to 50m
• Comprehensive diagnostics and error reporting
• Wall mounting

Specs:

Model: Forecourt
AccuracyExceeds EC Directive: 86/217 (to +/- 0.5% of full scale reading)
Reading Accuracy: 0.1 bar / 1 psi / 5 kPa / 0.1 kg/cm²
Maximum Inlet Pressure: 16bar / 232psi / 1600kPa / 16.3kg/cm²
Inflation Flow: 400 l/min (@10 bar supply)
Hose Length: 7.6m
Connection: Twin Lock-On
