BT0-5030 90° Female O-Ring x Air-O-Crimp Hose Fitting with 16mm Metric Port – #6

Description

The BT0-5030 90° Female O-Ring x Air-O-Crimp Hose Fitting with 16mm Metric Port is engineered for mobile air conditioning systems that require compact routing along with an integrated metric access port.

This fitting features a 6 Air-O-Crimp clamp-style hose connection, a 6 female O-ring (FOR) sealing surface with 5/8-18 threads, and a built-in 16mm metric port (16MMPT) for compatible service fittings, charging adapters, or system accessories.

The 90-degree configuration reduces hose stress, improves clearance around tight engine components, and simplifies installation in confined areas. The female O-ring connection provides a dependable, serviceable seal when paired with the proper O-ring. Meanwhile, the Air-O-Crimp clamp interface ensures a secure mechanical bond to 6 universal or nylon barrier hose when installed using approved clamp tools.

Constructed from durable steel, the BT0-5030 resists vibration, pressure cycling, and demanding operating environments commonly found in:

• Automotive A/C systems

• Heavy-duty trucks

• Agricultural equipment

• Construction machinery

• Off-road vehicles

This fitting is designed exclusively for Air-O-Crimp clamp-style hose assemblies and is not compatible with EZ-Clip systems.

When your system requires a 6 hose connection with a 90° turn and integrated 16mm metric access, the BT0-5030 provides a durable and professional-grade solution.

Product Specifications

• BTRAC Part Number: BT0-5030

• Fitting Type: Female O-Ring (FOR) x Air-O-Crimp with 16mm Metric Port

• Orientation: 90°

• Fitting Size: 6 (3/8″ nominal)

• Hose Size: 6

• Thread Size: 5/8-18

• Port Type: 16mm Metric Port (16MMPT)

• Crimp Style: Air-O-Crimp (Clamp Style)

• Material: Steel

• Application: Mobile A/C hose assemblies

• Compatible Hose Type: Universal / Nylon Barrier Hose

Cross References

• AN: AN3121-3C

• Eaton / Weatherhead: 54719-06-06-S

• Other References: 461-7933

• BTRAC: BT0-5030
